Heating buffer tank without heat exchanger

Buffer storage volume: 800 liters
Diameter without insulation: 79 cm
Diameter with insulation: 99 cm
Height without insulation: 184 cm
Height with insulation: 198 cm
Tank operating pressure: 3 bar/95°C
Weight: 108 kg
Insulation: 10 cm polyester (material similar to wool), removable!
See the drawing for connectors.

Find the corresponding heating pad and sensors in our online store.

More information:

Buffer storage without heat exchanger

Its specialization is the placement of the connectors on one side, within a 90-degree angle, so you can access the joints even when cornered. The steel container is not treated inside (it doesn't need to be!), it has a single layer of primer paint on the outside.
In this buffer tank, you store the water that is also circulated in your heating system. In this, the water in the closed circuit is heated directly by the boiler with a water fireplace or heat pump.
It can also be heated with an electric heating pad. To produce bath water (domestic hot water, DHW), you can heat the tap water with the hot water from the tank in the case of two heat exchanger types.

If you want to heat the domestic hot water itself, i.e. the water flowing from the tap, in the tank, choose an indirect hot water storage tank, boiler!

Legend:

1. Aesthetic PVC cover in RAL 9006
2. Apply a thick primer to the buffer tank.
3. High-quality, thick, optional thermal insulation.
4. Buffer tank made of low carbon steel.

Warranty: 3 years
