12V 800W + 300W charge controller and magnetic brake for AC windmill. Wind generator + solar panel hybrid controller charging controller

Charge controller for wind turbine and solar panel

Input: 12V AC for 3 phase windmill
Output: 12V DC
Output: 12V DC
Maximum power: 800W
Maximum solar panel power: 300W
Maximum input voltage: 60V
Battery connection wire: min 6mm
Maximum distance to battery: 3m
Maximum charging current: 40A
Maximum wind speed: 2500 rpm
Minimum voltage to turn on the charge controller: 6V
Battery charging mode: 12.6V
Maximum battery voltage: 14.8V (braking function starts above it)

For indoor use only, the charge controller is NOT waterproof!

Recommended minimum battery: 12V 100A
Lighting diodes meaning: Charging, Battery connected, Loaded, Brake. If required, it can even be ordered with an LCD display, so please contact our Customer Service.
Charge regulator that brakes thewindwheel.

Size: 30x20x15 cm
Metal housing design with cooling fins

Hybrid charge controller for 12 V 800W wind generator

Charging controller for a maximum 800 Watt three-phase wind wheel, to which you can connect up to 300 W solar panels.
The charge controller also monitors the overspeed of the wind wheel, so it is an essential tool for the I-700 wind power plant.
The charge controller automatically detects the battery voltage in each case and sets the appropriate output voltage. It is important to choose the I-700 24V wind generator for a 24V battery system, while the I-700 12V wind turbine for a 12V battery system!

It is important that both the windmill and the charging controller are NOT allowed to operate without a battery !
