Pump control

Power voltage: 230V 50Hz ± 10%
Ambient temperature: -10 ... + 50 °C
Switching current: 6 A
Temperature measurement range: 0 ... 90 °C
Temperature setting range: 5 ... 80 °C
Maximum sensor temperature: -10 ... 120 °C
Sensor length: 1.2 m

More information:

Thermostat for pumps and for boilers

The E110 thermostat is designed to control a heating circulation pump.
The function of the thermostat is to turn on the pump , when
the temperature exceeds the set value and shutdown,
when the boiler cools down. This prevents excessive operation of the pump,
which allows you to save electricity (from using the boiler
depending on it you can save up to 60%) and thus extend
the service life of the pump. This increases reliability and reduces
maintenance costs.

The thermostat is equipped with an anti-stop function that protects the pump.
every 15 days 15 turns on the pump for seconds and
with the frost protection function - if the temperature is below 5 °C sinks,
the pump turns on.

E110 Pump control temperature switch controller 230V 50Hz
