Temperature sensor PT100 Temperature sensor sensor plate -50°C - +300°C

PT100

Measuring range -50°C - +300°C
Response time: 0.25 sec
Standard: DIN EN 60751
Sensor head size: 2x1x3 mm

PT100 sensors are used in various areas such as:

Industrial process control: Temperature measurement and regulation in factories and plants.
Laboratory applications: Accurate temperature measurement in laboratories and research institutions.
Food industry: Temperature control of food and beverage processes.
< span style="color: #000000;">Medicine: Temperature detection and regulation of medical devices and equipment.

PT100 sensors provide accurate and reliable measurement results, which is important in various industrial and research applications where temperature control and monitoring can be critical.

PT100 temperature sensor board

The PT100 is a high-precision temperature sensing sensor that uses the change in platinum resistance value to measure temperature.
The PT100 is one of the most common types of RTD (Resistance Temperature Detector) sensors that use a change in platinum resistance to detect temperature.
The PT100 sensor is made of platinum wire or plate, and its resistance changes linearly with temperature. RTD sensors provide accurate and stable measurements over a wide temperature range, and their measurement accuracy is generally better than other types of temperature sensors.
The PT100 sensors have a resistance of 100 ohms at 0°C, hence their name "PT100". The value of the resistance changes with temperature, and the values ​​measured by the sensor are usually transmitted in a 3- or 4-wire design to increase the measurement accuracy.

Temperature sensor boilers, buffer tanks for heating control.
