Gas-liquid heat exchanger Freon heat exchanger 10 plates Ba-68-10-F for refrigerants 0.68m²

Gas-liquid heat exchanger

Number of plates: 10
Heat exchange surface:0.680 m²
Material: 316L stainless steel with vacuum brazed copper
Heating capacity heat pump / for air conditioning / cooling unit: 8 kW
Refrigerant / Gaseous media connection: φ22 - 7/8" for brazing
Traditional liquid media connection: 1" - DN 25
Operating pressure: Up to 45 bar ( this is the maximum permissible pressure)
Pressure tests before commissioning: > 60 bar
Flow rate: 22 m³/h
Connection method: counter-current

Freon heat exchanger

Gas/Freon heat exchanger designed with two channels, one for gas/Freon/refrigerant and the other for liquid, which can be water or glycol solution. Heat exchangers for Freon and similar media are primarily used as condenser-evaporators in heat pumps or similar devices such as refrigeration units and air conditioners. One of the key design features that differentiates this model from traditional plate heat exchangers is the resistance to the higher pressure it can generate when working with freon or refrigerants (up to 45 bar) and the prepared connections for gas media.

Main features:

• Number of discs: 10 discs
• Connections
  • Gas side: 7/8" tube (φ22)
  • Liquid side (heat absorption side): 1"
• Heat exchange surface:0.680 m²

• Estimated heat pump / unit / air conditioning power: 8 kW
• Operating pressure on the gas side: up to 45 bar

Heat exchange surface of the Ba-68-F series of heat exchangers for freon and gas The heat exchange surface of the Ba-68-10-F freon liquid heat exchanger is 0.68 m², and this the smallest heat exchanger in the Ba-68-F series.

The 10-plate heat exchanger is the smallest in the Ba-68 series, designed for gas and liquid. If your application requires a larger heat exchanger surface than 0.68 square meters, choose a heat exchanger with a larger number of plates. The Ba-68 series includes 8 models, the largest of which exceeds 4 square meters.
